Full Automatic Headband N95 Mask Machine

The full-automatic headband N95 mask machine is a full-automatic machine used to produce folding mask production lines. It uses ultrasonic technology to weld 3-6 layers of PP non-woven fabric, activated carbon filter material and filter material. The whole set of equipment is integrated and fully automatic folding production technology through non-woven fabric welding, ear band welding, printing, half folding, edge sealing, rolling cutting, etc., and can process 3M 9001, 9002, etc. and other folding masks. The raw materials selected according to product requirements can produce masks that meet different standards such as FFP1, FFP2, N95, etc. The whole production process does not require personnel to participate, and the finished product is fully automated.

Full Automatic Headband N95 Mask Machine

No.

Items

Descriptions

1

Basic specification

Applicable for N95 mask with machine

ear hook face mask welding

2

Machine weight

3000kgs

3

Electrical specification

220V±5%, 50HZ, single phase, 13kw

4

Air pressure

6Kg/cm2, 750L/Min (required air compressor7.5kw)

5

Required environment

humidity 5% -35% HR, temperature 10-35 degrees, no dust, no flammable and corroded air

6

Machine size

(please refer to the physical size)

8286 × 1500 × 1650mm

7

Capacity

65+ per minute

8

System power consumption

ultrasonic

1500W*4 sets

9

Ultrasonic system frequency

20KHz

ENQUIRY
